| A | 43 | mm | |
| H (Measured with gauging shaft, nominal dimension d and length about 50 mm.) | 28 mm ±0.05 | ||
| M1 | 9 | ||
| O1 (ISO 4762-8.8) | M4x25 | ||
| T (For transverse loads on the Linear Bushing opening and when approaching maximum load, as well as when dimensional accuracy is strictly required. ) | 75 | mm | |
| U1 (DIN 7980, discontinued. Spring washer commercially available.) | 4 | mm | |
| V | 5 | mm |
| e | 29 | ||
| m | 5,80 | ||
| N | 8 | mm | |
| O2 (ISO 4762-8.8 oder ISO 4017-8.8, only applicable for bolting with steel or cast iron threads. ) | M4x12 | ||
| T | 5,50 | mm | |
| U2 (DIN 125) | 4 | mm |
| m | 1,95 | kg |
