seal material | epdm | ||
hex size | 24 mm | ||
Outside diameter | 27 mm | ||
Length | 56 mm | ||
maximum operating temperature | 150 °c | ||
Diameter | 10 nom | ||
Material | brass | ||
Type | coupling |
valve included | yes | ||
Application | pneumatic & fluid handling | ||
maximum operating pressure | 35 bar | ||
minimum operating temperature | -40 °c | ||
flow rate | 950 (air), 14 (water) l/min | ||
connection thread size (inch) | 3/8 | ||
Version | double shut-off | ||
connection type | female thread - parallel |
