| media | phosphate-ester base hydraulic fluids | ||
| compatible fitting | 43 series | ||
| maximum operating temperature | 176 °f, 80 °c | ||
| cover material | epdm rubber, green | ||
| hose inner tube material | epdm rubber | ||
| hose outside diameter | 1.86 inch, 47 mm | ||
| hose inside diameter | 1-1/4 inch, 31.4 mm | ||
| Weight | 1.16 lb/ft, 1.73 kg/m |
| Application | phosphate-ester base hydraulic fluids | ||
| hose cover type | epdm rubber, green | ||
| minimum bend radius | 16-1/2 inch, 420 mm | ||
| hose reinforcement material | 2 braid steel wire | ||
| maximum operating pressure | 1625 psi, 11.2 mpa | ||
| nominal hose inside diameter | 31 | ||
| minimum operating temperature | -40 °c, -40 °f | ||
| hose i.d. (size) | -20 |
