| Distance from side face to pressure point | a | 8,50 | mm |
| Chamfer dimension (large side face) | r1,2 | min.0.3 | |
| Shoulder diameter of inner ring (small side face) | d2 | 22,60 | mm |
| Width | B | 10 | mm |
| Bore diameter | d | 17 | mm |
| Chamfer dimension (small side face) | r3,4 | min.0.2 | |
| Shoulder diameter of outer ring (large side face) | D1 | 29,30 | mm |
| Shoulder diameter of inner ring (large side face) | d1 | 22,60 | mm |
| Outside diameter | d2 | 35 | mm |
