| Application | petroleum base hydraulic fluids & lubricating oils | ||
| compatible fitting | 43 series | ||
| maximum operating temperature | 257 °f, 125 °c | ||
| cover material | synthetic rubber super abrasion resistant | ||
| hose inner tube material | synthetic rubber | ||
| maximum operating pressure | 4000 psi, 28 mpa | ||
| media | hydraulic fluids, lubricants | ||
| minimum operating temperature | -40 °f, -40 °c | ||
| hose cover type | supertough cover |
| cover color | black | ||
| specifications met | iso 18752 | ||
| minimum bend radius | 2-1/2 inch, 65 mm | ||
| hose reinforcement material | 4 spiral | ||
| hose outside diameter | 0.78 inch, 19.8 mm | ||
| nominal hose inside diameter | 10 | ||
| hose inside diameter | 3/8 inch, 9.5 mm | ||
| Weight | 0.60 kg/m, 0.4 lb/ft | ||
| hose i.d. (size) | -6 |
