| Recommended tightening torque for set screw | 11,5 N-m | ||
| Operating temperature min. | -20 °C | ||
| C - Dynamic load rating | 25,7 kN | ||
| N1 - Mounting hole length | 21 mm | ||
| L1 - Housing foot length | 54 mm | ||
| J - Mounting holes distance | 127 mm | ||
| H1 - Housing foot height | 19 mm | ||
| G - Grease fitting | M6x1 | ||
| A1 - Housing top width | 31 mm | ||
| Brand | SNR |
| Operating temperature max. | 100 °C | ||
| C0 - Static load rating | 15,2 kN | ||
| S - Dist. cent. of raceway to face IR on side opp. lock. device | 9,5 mm | ||
| N - Mounting hole dimension | 17 mm | ||
| L - Housing length | 167 mm | ||
| H2 - Housing height | 94 mm | ||
| H - Distance mounting base to centerline spheric. seating diam. | 47,6 mm | ||
| d1 - Outer dia of eccent. Lock. collar / nut of adapter sleeve | 51,1 mm | ||
| A - Housing width | 48 mm |
