| A | 87 | mm | |
| D | 30 | mm | |
| E1 (Two centering recesses for stud bolts) | 45 | mm | |
| H (In relation to nominal shaft dimension "d") | 40 mm ±0.01 | ||
| H4 | 22 | mm | |
| N1 | 34 | mm | |
| SW | 6 | ||
| S1 | M12 | ||
| V | 8 | mm |
| B | 40 | ||
| e | 64 mm ±0.15 | ||
| E2 (Two centering recesses for stud bolts) | 26 | mm | |
| H1 | 70 | mm | |
| m (In relation to nominal shaft dimension "d") | 43.5 mm ±0.01 | ||
| N2 | 26 | mm | |
| S (Fixing screws ISO 4762-8.8) | 10,50 | ||
| S2 (Two centering recesses for stud bolts) | 8 |
| m | 0,48 | kg |
| MA | 30 | Nm |
