| adjusting screw | stainless steel | ||
| bonnet | stainless steel | ||
| elastomers | nitrile rubber | ||
| flow flow dm3secbar | 8 dm3/(s.bar) dm3/sec | ||
| gauge port | 1/4" nptf | ||
| maximum inlet pressure pressure bar | 31 bar | ||
| operating temperature f temperature fahrenheit min to max range | -40 ... 175 °f | ||
| outlet pressure adjustment imperial pressure psig min to max range | 7 ... 145 psi | ||
| Port size | 1/4" nptf | ||
| relievingnonrelieving | relieving |
| body | stainless steel | ||
| brochure | z7844br_f22-imi-pe_en_lr.pdf | ||
| flow flow dm3sec | 8 dm3/sec | ||
| gauge | no gauge | ||
| maximum inlet pressure imperial pressure psi | 450 psig | ||
| Medium | compressed air | ||
| operating temperature temperature celsius min to max range | -40 ... 80 °c | ||
| outlet pressure adjustment pressure bar min to max range | 0.5 ... 10 bar | ||
| range | r38 |
