| Length (L) | 15 | m |
| Operating voltage (min ... max) | 10 V DC ... 30 V DC | ||
| 1. connection type | Straight female connector, M8x1, 3-pin | ||
| Function indication | ‒ | ||
| Suitable for flexing installation | ✓ | ||
| Weld spark resistant | ✓ | ||
| Cable diameter D | 4.1 mm ±0.2 | ||
| Bending radius, flexing | ≥ 10xD | ||
| Maximum permissible travel speed | 3.3 m/s - for 5 m travel path (typ.) up to 5 m/s - for 0.9 m travel path | ||
| Fixed arrangement ambient temperature (min ... max) | -40 °C ... +85 °C | ||
| Protection type | IP68 |
| Type of cable | PUR black | ||
| 2. connection type | Flying lead | ||
| Operating voltage indicator | ‒ | ||
| Can withstand torsion | ✓ | ||
| Cable cross-section | 3x0,25 | ||
| Bending radius, stationary | ≥ 5xD | ||
| Bending cycles | > 10 million | ||
| Maximum permissible acceleration | 30 | ||
| Flexible arrangement ambient temperature (min ... max) | -25 °C ... +85 °C |
