| Size | 125 | ||
| Corrosion resistance class CRC | 1 - Low corrosion stress | ||
| Ambient temperature | -40 °C ... 90 °C | ||
| Note on materials | RoHS-compliant | ||
| Material bolt | Galvanised steel | ||
| Material disc | Galvanised steel | ||
| Material lock | Spring steel, galvanised |
| Based on standard | ISO 15552 | ||
| Suitability for the production of Li-ion batteries | Metals with more than 5% copper by mass are excluded from use. Exceptions are printed circuit boards, cables, electrical plug connectors and coils | ||
| Product weight | 1.860 g | ||
| Material mounting | Die-cast aluminium | ||
| Material bearing | Polymer | ||
| Material screws | Galvanised steel |
