| Mounting position | optional | ||
| Operating pressure | 1,5 bar ... 10 bar | ||
| Corrosion resistance class CRC | 2 - Moderate corrosion stress | ||
| Media temperature | -20 °C ... 60 °C | ||
| Product weight | 255,5 g | ||
| Pneumatic connection, port 2 | Flange 1/4 with NAMUR port pattern | ||
| Note on materials | Contains paint-wetting impairment substances RoHS-compliant |
| Design | Connections rotated 180° | ||
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] | ||
| Storage temperature | -20 °C ... 60 °C | ||
| Ambient temperature | -20 °C ... 60 °C | ||
| Type of mounting | With through-hole | ||
| Pneumatic connection, port 4 | Flange 1/4 with NAMUR port pattern | ||
| Material sub-base | Wrought aluminium alloy |
