| Brand | NTN | ||
| Ca - Dynamic axial load rating | 223 kN | ||
| Cua - Limit axial load rating | 23,3 kN | ||
| Nlim - Grease lubrication limit speed | 870 tr/min | ||
| Tmax - Max operating temperature | 120 °C | ||
| da min - Min shoulder diameter IR | 199 mm |
| rs - Min fillet radius | 1,5 mm | ||
| C0a - Static axial load rating | 720 kN | ||
| Nlim - Oil lubrication limit speed | 1200 tr/min | ||
| Tmin - Min operating temperature | -40 °C | ||
| Da max - Max shoulder diameter OR | 186 mm |
| Fabricante | Referencia |
|---|---|
| FAG | 51232-MP (FAG) |
