R902552480 Bosch Rexroth

REXROTH R902552480 BOMBA DE EMBOLOS AXIALES

A1VO035DRS0C200/10MRVB2S51000000-0

$1.698,11 $3.396,22 -50%
disponible con envío de 7 a 15 días a United States

Especificaciones

  • For load-sensing systems in smaller mobile machines
  • Size 18 … 35
  • Nominal pressure 250 bar
  • Maximum pressure 280 bar
  • Open circuit

Junta FKM (Standard)
Peso 17Kg
Product (Axial piston unit) A1V
Size (Displacement) 35 cm³
Add. controller - Load sensing Load sensing
Adjustment Adjustable setting
Port and mounting threads ISO 6149 (metric)
Sealing Material FKM (Standard)
Mounting flange ISO 3019-1 (SAE), 101-2 (B)
Through drive Without through drive
Additional functions + Sensors Without
Speed of Rotation 3000 rpm
Max. Displacement 35.0 cm³
Internal drain line No
Approval Company (external) No
Language code f. test certif. without
Paint/top coat without
Type of Operation Open circuit
Control device Pressure controller
Controller design & mounting Cartridge
Series Series 1, Index 0
Direction of rotation right-hand (view on shaft end)
Shaft End 1" 15T 16/32DP (recess)
Service line connections Threaded ports opp side
Additional options Without
Reduced Displacement Volles Hubvolumen
Operating pressure 250 bar
Max. Output Flow 105.0 l/min
Differential Pressure FR 14.0 bar
Test certificate Without
Paint/Primer without
Painting unpainted
